Asus B250-MINING-EXPERT
B250 ATX: B250 Socket 1151 For Intel 6th 7th Gen. Processors
2x DDR4, 4x SATA 6Gb/s, 1x PCIEx16, 18x PCIEx1, USB 3.1, Gigabit LAN, HDMI, BTC Mining
$10 discount when purchase with CPU and Memory while stock last
$69.00

Product Availability: Stock reports there should be high level quantities in store at this time. To reserve stock please place an order online (*no* payment details or commitment required to place order online, but please only order if you plan on getting it (stock availability dependent)).


Intel LGA-1151 ATX mining motherboard with 19 PCIe slots, Triple-ATX12V power delivery, voltage-stabilization capacitors, and mining mode design

  • World’s first 19-slot motherboard for multi-GPU mining
  • Exclusive triple-ATX12V design and 19 decoupling capacitors for stable power delivery
  • ASUS PCIe Slot State Detection indicates the status of each GPU connection for easy management and debugging
  • Unique Mining Mode for hassle-free setup of your mining rig — no BIOS tweaks required
  • Intel LAN and LANGuard for the best networ performance



  • CPU

    Intel® Socket 1151 for 7th/6th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
    Supports Intel® 14 nm CPU
    Supports Intel® Turbo Boost Technology 2.0
    * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
    * Refer to
    www.asus.com for CPU support list

  • Chipset

    Intel® B250

  • Memory

    2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory
    Supports Intel® Extreme Memory Profile (XMP)
    * Refer to
    www.asus.com for the Memory QVL (Qualified Vendors Lists).
    * Due to Intel® chipset limitation, DDR4 2400MHz memory frequency is only supported by 7th Generation Intel® processors. Higher memory modules will run at the maximum transfer rate of DDR4 2400MHz.
    ** Due to Intel® chipset limitation, DDR4 2133MHz and higher memory modules on 6th Generation Intel® processors will run at the maximum transfer rate of DDR4 2133MHz.

  • Graphic

    Integrated Graphics Processor- Intel® HD Graphics support
    VGA output support : HDMI port
    - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
    Maximum shared memory of 1024 MB

  • Expansion Slots

    1 x PCIe x16 (x16 mode)
    18 x PCIe x1

  • Storage

    4 x SATA 6Gb/s port(s),

  • LAN

    Intel® I219V, 1 x Gigabit LAN Controller(s)

  • Audio

    Realtek® ALC887 8-Channel High Definition Audio CODEC

  • USB Ports

    Intel® B250 Chipset :
    6 x USB 3.1 Gen 1 port(s) (4 at back panel, , Type-A, 2 at mid-board)
    Intel® B250 Chipset :
    4 x USB 2.0/1.1 port(s) (2 at back panel, , 2 at mid-board)

  • Special Features

    ASUS 5X Protection III :
    - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
    - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
    - ASUS Overvoltage Protection: World-class circuit-protecting power design
    - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
    - ASUS DIGI+ VRM: 6 Phase digital power design

  • Back I/O Ports

    1 x PS/2 keyboard (purple)
    1 x PS/2 mouse (green)
    1 x HDMI
    1 x LAN (RJ45) port(s)
    4 x USB 3.1 Gen 1 (blue) Type-A
    2 x USB 2.0
    3 x Audio jack(s)

  • Internal I/O Ports

    1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
    1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
    1 x COM port(s) connector(s)
    4 x SATA 6Gb/s connector(s)
    1 x CPU Fan connector(s) (1 x 4 -pin)
    1 x Chassis Fan connector(s) (1 x 4 -pin)
    1 x S/PDIF out header(s)
    3 x 24-pin EATX Power connector(s)
    1 x 8-pin ATX 12V Power connector(s)
    1 x Front panel audio connector(s) (AAFP)
    1 x System panel(s)
    3 x 4-pin AUXPWR Header

  • Accessories

    User's manual
    I/O Shield
    2 x SATA 6Gb/s cable(s)
    1 x Supporting DVD

  • BIOS

    64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS3.0, ACPI 6.0, ASUS EZ Flash 3, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information

  • Manageability

    WfM 2.0, DMI 3.0, WOL by PME, PXE

  • Operating System

    Windows® 10 64-bit
    Windows® 7 64-bit *1

  • Form Factor

    ATX Form Factor
    12 inch x 9.1 inch ( 30.5 cm x 23.1 cm )

  • Note

    1.Windows® 7 64-bit is only supported when using 6th Generation Intel® Processors




  • All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.

  • Specifications and features vary by model, and all images are illustrative. Please refer specification pages for full details.

  • PCB color and bundled software versions are subject to change without notice.

  • Brand and product names mentioned are trademarks of their respective companies.


  • Specifications and features vary by model, and all images are illustrative. Please refer specification pages for full details.

  • *Precise specifications and features vary by model . Please refer to the specification page

  • The product (electrical , electronic equipment, Mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for disposal of electronic products.

  • The use of trademark symbol (TM, ®) appears on this website means that the word text, trademarks, logos or slogans, is being used as trademark under common laws protection and/or registered as Trademark in U.S. and/or other country/region.




For more information, please visit this webpage.
This product was added Tuesday 16 January, 2018.
This product was last modified on Friday 13 September, 2019.
